GP2 1200 250 12 D
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
5
1.0 - Model code
1.1 - GP2 Technical Data
MODELS GP2 500 GP2 1200 (D / FF)
(6)
GP2 1500 (D / FF)
(6)
GP2 2000 (D / FF)
(6)
MODEL POWER 150 W 250 W 500w 800 W
Motor voltage 12 V 12 V 12 V 12 V 24 V
Maximum instantaneous pull 220 Kg (485.0 lb) 550 Kg (1212.5 lb) 680 Kg (1499.0 lb) 900 Kg (1984 lb) 900 Kg (1984 lb)
Maximum work load 70 Kg (154.3 lb) 170 Kg (374.8 lb) 250 Kg (551.0 lb) 350 Kg (772.0 lb) 350 Kg (772.0 lb)
Work load 35 Kg (77.2 lb) 50 Kg (110.2 lb) 85 Kg (187.0 lb) 120 kg (265.0 lb) 120 kg (265.0 lb)
Current consumption at work
load
(1)
29 A 35 A 76 A 96 A 50 A
Maximum recovery speed
(2)
38.9 m/min
(83.7 ft/min)
31.2 m/min
(102.4 ft/min)
25.5 m/min
(83.7 ft/min)
29.6 m/min
(97.1 ft/min)
29.6 m/min
(97.1 ft/min)
Recovery speed at work load
(2)
28.5 m/min
(33.8 ft/min)
25.1 m/min
(82.3 ft/min)
10.3 m/min
(33.8 ft/min)
20.0 m/min
(65.6 ft/min)
20.1 m/min
(65.9 ft/min)
Minimum motor cable cross
section
(3)
4 mm² (AWG 12) 10 mm² (AWG 7) 10 mm² (AWG7) 16 mm² (AWG5) 10 mm² (AWG7)
Circuit breaker
(4)
40 A 50 A 80 A 40 A
Deck thickness
(5)
20 ÷ 40 mm (3/4” ÷ 1” 9/16)
Weight - model without drum 6 kg (13.2 lb) 8 kg (17.6 lb) 10.2 kg (22.4 lb)
Weight-model with drum - 9 kg (19.8 lb) 11.5 kg (25.3 lb)
Weight-model Free Fall - 10.9 kg (24.0 lb) 10.9 kg (24.0 lb)
(1) After an initial period of use.
(2) Measurements taken with a gypsy for 6 mm chain
(3) Minimum recommended value for total length L= <20 m.
Determine the cable cross section according to the length of the wiring.
(4)Withspeciccircuitbreakerfordirectcurrent(DC)anddelayedcircuitbreaker(thermal-magneticorhydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
GYPSY (*) 6 mm 7 mm - 1/4” 8 mm 5/16”
Chain size
6 mm 6 mm 7 mm 7 mm 1/4” 1/4” 8 mm 8 mm 5/16”
DIN 766 ISO DIN 766 ISO*** G4 BBB DIN 766 ISO*** G4
Rope size**
1/2” (12.7 mm) 1/2” (12.7 mm) 1/2” (12.7 mm)
(*) For gypsy codes, see the exploded drawing from page 14 to 17
(**) The values in the table refer to a polyester rope featuring 3 strands with rope/chain junction according to the Quick
®
system
(***) ISO EN 818-3.
READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USING THE PRODUCT. IF IN DOUBT, CONTACT YOUR QUICK
®
DEALER.
QUICK
®
RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT
PRIOR NOTICE. IN CASE OF DISCORDANCE OR ERRORS IN TRANSLATION BETWEEN THE TRANSLATED VERSION AND THE ORIGINAL TEXT IN THE ITALIAN
LANGUAGE, REFERENCE WILL BE MADE TO THE ITALIAN TEXT.
VOLTAGE (V)MODEL
SERIES NAME
POWER (W)
DRUM (D)
COVER (-)
FREE FALL (F)
