12
EN
HRC - REV005C
MULTIPURPOSE CONTROL PANEL
The Quick
®
multipurpose control panel is an instrument designed for the remote control of various moving systems on
board a boat, including mini-crane, gangplank, swimming ladder, anchor hoist.
The control panel with LED torch (HRC1002L, HRC1004L, HRC1006L, HRC1008L models) offers the following advantages:
• SOS flashing function.
• Temporary ON function of the torch.
• Low power absorption.
• Battery save function.
• Universal power supply with protection against polarity inversion.
INSTALLATION
BEFORE USING THE INSTRUMENT PLEASE STUDY THIS USER MANUAL. IN CASE OF ANY DOUBT
PLEASE CONTACT THE RETAILER OR QUICK
®
CUSTOMER SERVICE.
In case of discordance or errors in translation between the translated version and the original text in the Italian
language, reference will be made to the Italian or English text.
This device was designed and constructed for use on recreational crafts.
Other forms of use are not permitted without written authorization from the company Quick
®
.
The control was designed for the purposes described in this user manual. The company Quick
®
does not accept any
responsibility for direct or indirect damage caused by the improper use of the device, by incorrect installation, or for
any errors in this user manual.
WARNING:
the electrical appliance controlled by the control panel must be provided with safety systems to
prevent damage to persons, things, or the environment that might result from the defective operation of the
control panel.
THE OPENING OF THE INSTRUMENT BY UNAUTHORIZED PERSONNEL MAKES THE WARRANTY VOID.
THE PACKAGE CONTAINS:
control panel - support - socket - socket seal and cover - screws - drilling template -
personalised adhesives (only in certain models) - Installation and user manual (with drilling template to page 45).
FITTING THE SOCKET
A typical installation procedure is described below.
It is not possible to define a single procedure that is applicable in every situation.
Adapt the procedure described here to your own requirements.
Identify the most appropriate position for the socket seating on the basis of the following criteria:
• The socket must be positioned so that it can easily be reached by the operator.
• Choose a clean, smooth, flat location.
• Rear access is required for installation and maintenance.
• There must be sufficient space behind the chosen position for the passage of the socket cable.
• The back of the socket must not be exposed to contact with water or humidity.
• Take particular attention when drilling the panels or parts of the boat. The holes must not weaken or cause the
breakage of structural elements of the boat.
CHARACTERISTICS AND INSTALLATION
F
F
