PROGRAMMING THE INSTRUMENT AND THE BATTERY CHARGER
In order to enter the system main menu Keep the “ENTER” button pressed down for 3 seconds until the backlit LCD display
starts to blink. Release the “ENTER” button
Use the
p and q buttons (UP and DOWN) to scroll through the functions of the main menu.
The selected function is the one that appears between the symbols
u and t .
FUNCTION SYNTHETIC DESCRIPTION
BATTERY TYPE Displays the type of batteries selected on battery charger.
CAN GROUP Sets the CAN group of the battery charger.
CAN PRIORITY Sets the priority of the battery charger.
MONITOR MODE Enable or disable the monitoring mode.
FLOAT THRESHO Allows the setting of the FLOAT threshold.
MAX CURRENT Allows the setting of the maximum output current.
SILENT MODE Allows enabling or disabling of silent mode.
RESET Allows the reset of the battery charger.
CONFIG RDS Allows the setting of the parameters of the RDS 1562 remote panel.
EXIT Exits the menu.
The programmable
functions inside
the systems main
menu are:
u
B A T T E R Y T Y P E
t
C A N G R O U P
q
The symbols p and q indicate the scrolling direction
(UP and DOWN) for the functions’ selection in the main menu.
The structure
of the menu:
PROGRAMMING
Battery type
CAN group
CAN priority
Monitor mode
THR. float
Max current
EXIT
Open free ele
Sealed liquid
Gel
AGM Spiral
AGM
Li-ION
Group A
Priority 1
Group B
Priority 2
Group C
Priority 3
Group A
Group B
Group C
5%
10%
1
10%
30%
2
15%
50%
3
20%
70%
4
25%
90%
5
30%
100%
Priority 1
On warnings
On errors
Priority 2
Priority 3
Disable
Enable
100%
Language
90%
RDS Group
80%
RDS Priority
70%
Acoustic alarm
Net scanning
60%
Backlight
Key beep
50%
LCD Contrast
Exit
Exit
Disable
Disable
Disable
Disable
No
Enable
Enable
Enable
Enable
Yes
English
Italiano
Silent mode
Reset
RDS settings
Francais
Espanol
Deutsch
