Quick SBC NRG Series User Manual

29
GB
SBC NRG HIGH POWER - REV001A
PROGRAMMING THE BATTERY CHARGER
Exit
DATA ITEM SYNTHETIC DESCRIPTION
BATTERY TYPE
Allows the settings of the type of batteries to be charged.
CAN GROUP Allows the settings the group of the battery charger on the CAN network.
CAN PRIORITY Allows the settings of the priority of the battery charger on the CAN network.
MONITOR MODE Allows enabling or disabling the monitor mode.
FLOAT THRESHO Allows the setting of the FLOAT threshold.
MAX CURRENT Allows the setting of the maximum output current.
SILENT MODE Allows enabling or disabling of silent mode.
LANGUAGE Language setting.
EXIT Exiting from menu.
THE STRUCTURE OF THE MENU
BATTERY TYPE
CAN GROUP
CAN PRIORITY
MONITOR MODE
FLOAT THRESHO
MAX CURRENT
LANGUAGE
EXIT
Open Liquid
Sealed Liquid
GEL
AGM
Group A
Group B
Group C
Exit
5%
10%
15%
20%
25%
30%
Exit
Exit
Priority 1
Priority 2
Priority 3
Exit
Disable
Enable
Exit
100%
90%
80%
70%
60%
50%
Disable
Enable
Exit
English
Italiano
SILENT MODE
Francais
Espanol
Deutsch
Exit
The programmable functions in the systems main menu are:
u
BATTERY TYPE
t
can GR oup
q
PROGRAMMING THE BATTERY CHARGER
In order to enter the system main menu Keep the “ENTER” button pressed down for 3 seconds until the backlit LCD
display starts to blink.
Release the “ENTER” button.
The backlight of the LCD display turns itself on confirming the entry into the “systems main menu”.
Use the
p and q buttons (UP and DOWN) to scroll the functions through the main menu.
The currently selected function is the one that appears between the symbols
u and t .
Main menu entrance screenful
The symbols
p and q indicate the
scrolling direction (UP and DOWN) for
the functions’ selection in the main
menu.
