Quickie Xenon User Manual

28
Technical Specifications continued
Maximum weight limit:
Xenon up to a load of 125 kg
Seat heights:
The choice of frames, forks and castors as well as the
size of the rear wheel (610mm (24")), (635mm (25"));
determines what seat heights are possible.
Table of Minimum and Maximum Values
Parameter Min. Max. Parameter Min. Max.
Overall length
with footrest
770 mm 1050 mm Seat surface
angle
0° 15°
Overall width 620 mm 760 mm Effective seat
depth
340 mm 500 mm
Folded length N/A N/A Effective seat
width
320 mm 460 mm
Folded width 270 mm 310mm Seat height at the
front edge
430 mm 570 mm
Folded height N/A N/A Backrest angle 75° 108°
Total weight 8.5 kg 13.0 kg Back height 250 mm 475 mm
Weight of
the heaviest
individual part
- 2.1 kg with 610mm
(24") rear wheel
Distance from
the footrest to the
seat
220 mm 520 mm
Static stability -
downhill
10° 10° Angle from leg to
seat
92° 100°
Static stability
- uphill (with anti-
tip tube)
10° 10° Distance from the
armrest to the
seat
N/A N/A
Static stability -
sidewards
10° 10° Front position of
the armrests
N/A N/A
Dynamic stability
- uphill power
consumption
N/A N/A Handrim diameter 540 mm 567 mm
Overcoming
obstacles
N/A N/A Horizontal axle
position
+ 30 mm + 13 mm
The wheelchair conforms to the following standards:
1. Requirements and test methods for static, impact and fatigue strengths (ISO 7176-8)
2. Flammability resistance of upholstered parts in accordance with ISO 7176-16 (EN 1021-1/2)
