Nameplate
The nameplate is located on either the cross-tube
assembly or the transverse frame tube, as well as on a
label in the owner’s manual. The nameplate indicates the
exact model designation and other technical
specifications. Please provide the following pieces of
information whenever you have to order replacement
parts or to file a claim:
• Serial number
• Order number
• Month/Year
Technical Specifications
Overall width:
With standard wheels including hand rims, close mount:
• in combination with aluminium side guard:
SW + 170 mm
• in combination with plastic clothes protector:
SW + 190 mm
• With extra-narrow hand rim fitting, overall width is
reduced by 20 mm.
• With standard wheels including hand rims and 4°
camber: SW + 250 mm
Overall length:
910 mm with SD 480 mm
Overall height:
1120 mm with BH 450 mm
Folded dimensions:
• with rear wheels approximately 270 mm
• without rear wheels approximately 250 mm
Weight in kg:
• Overall from 8.5kg
• Transportation (without footrest, wheels, side guard) 6kg
• Side guard (unit) 1.3 kg
• Wheels (unit) 2.2 kg
530mm
1050mm
805mm
970mm
