QuickJack 5000TL - Sheet2; Drawing View2; Drawing View3; Drawing View4

20.504in
520.8mm
43.126in
1095.4mm
FULL RISE
20.083in
510.1mm
41.853in
1063.1mm
TOPLOCK
14.232in
361.5mm
31.957in
811.7mm
LOWEST LOCK
2.756in
70.0mm
24.678in
626.8mm
FULLY LOWERED
SHEET 2 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5215922
5000TL FRAME
ASSEMBLY, R.H.
1:15
SCALE:
