QuickJack BL-3500SLX - Page 12

QuickJack™ Portable Car Jack 12 P/N 5900959 — Rev. L1 — December 2020
Model
BL-6000XLT BL-5000EXT BL-7000EXT
Lifting capacity per pair 6,000 lbs / 2,722 kg 5,000 lbs / 2,268 kg 7,000 lbs / 3,175 kg
A Collapsed height 3.6" / 91 mm 3" / 76 mm 3.6" / 91 mm
B Height, no blocks * 18.2" / 462 mm 17.6" / 447 mm 18.2" / 462 mm
C Height, small blocks 18.6" / 471 mm 18.4" / 467 mm 18.6" / 471 mm
D Height, tall blocks 19.4" / 493 mm 19.2" / 487 mm 19.4" / 493 mm
E Height, stacked blocks 21.6" / 548 mm 21.3" / 542 mm 21.6" / 548 mm
F Frame width 12.5" / 318 mm 11" / 278 mm 12.5" / 318 mm
G Block position, max spread 75.8" / 1,926 mm 66" / 1,676 mm 66" / 1,676 mm
H Block position, min spread 47.4" / 1,205 mm 37.4" / 951 mm 37.4" / 951 mm
I Frame length 86" / 2,185 mm 75" / 1,905 mm 76" / 1,930 mm
Individual frame weight 110 lbs / 50 kg 80 lbs / 36 kg 101 lbs / 46 kg
Power unit weight 35 lbs / 16 kg 35 lbs / 16 kg 35 lbs / 16 kg
Power Unit PRV setting 1,980 PSI 1,980 PSI 1,980 PSI
Sound (when raising/lowering) <70 dBA <70 dBA <70 dBA
Maximum allowed wind speed
<60 mph / <96.5 kph <60 mph / <96.5 kph <60 mph / <96.5 kph
* For reference purposes only; do not raise a Vehicle without Lift Blocks.
Height values may be .25 in / 7 mm different if measurement done with mechanism at full rise or on top lock.
Measurements may be up to 3 percent different based on amount of weight on lift, weight distribution, and
manufacturing tolerances.
Specifications are subject to change without notice.
