QuickJack BL-3500SLX - Specifications

QuickJack™ Portable Car Jack 11 P/N 5900959 — Rev. L1 — December 2020
Specifications
Model BL-3500SLX BL-5000SLX BL-7000SLX
Lifting capacity 3,500 lbs / 1,588 kg 5,000 lbs / 2,268 kg 7,000 lbs / 3,175
A Lowered height (frame only) 3" / 76 mm 3" / 76 mm 3.6" / 91 mm
B Height, frame only * 16.5" / 419 mm 17.5" / 440 mm 18" / 457 mm
C Height, 2" blocks 17" / 432 mm 18.4" / 460 mm 18.6" / 471 mm
D Height, 3" blocks 18.5" / 470 mm 19.2" / 480 mm 19.4" / 493 mm
E Height, stacked blocks 20" / 508 mm 21" / 534 mm 21.25" / 540 mm
F Frame width 10.6" / 268 mm 11" / 278 mm 12.5" / 318 mm
G Max lifting point spread 50.5" / 1,283 mm 60" / 1,517 mm 60" / 1,524 mm
H Min lifting point spread 26.7" / 678 mm 29.5" / 801 mm 29.5" / 749 mm
I Frame length 62" / 1,575 mm 70" / 1,778 mm 70" / 1,778 mm
Individual frame weight 60 lbs / 27 kg 78 lbs / 35 kg 96 lbs / 44 kg
Power unit weight (no fluid) 35 lbs / 16 kg 35 lbs / 16 kg 35 lbs / 16 kg
Power Unit PRV setting 1,980 PSI 1,980 PSI 1,980 PSI
Sound (when raising/lowering) <70 dBA <70 dBA <70 dBA
Maximum allowed wind speed
<60 mph / <96.5 kph <60 mph / <96.5 kph <60 mph / <96.5 kph
* For reference purposes only; do not raise a Vehicle without Lift Blocks.
Height values may be .25 in / 7 mm different if measurement done with mechanism at full rise or on top lock.
Measurements may be up to 3 percent different based on amount of weight on lift, weight distribution, and
manufacturing tolerances.
Specifications are subject to change without notice.
