Quicksilver 505CAB — System & Component Overview and Operaon
NEVER TRAILER THE CANVAS BIMINI OR BIMINI WITH
ENCLOSURE IN THE UPRIGHT POSITION.
The bimini canvas must be secured in the canvas boot with
the rails in the stored posion before trailering.
Canvas
Bimini
Enclosure panels
Bimini
Bimini with enclosure
Sun lounge may shi while underway. Verify that the outer
sun lounge panels are fully engaged into the deck support
slots and the center sun lounge panel locks in posion.
NEVER OPERATE THE VESSEL WITH THE CANVAS
ENCLOSURE UNLESS THERE IS VENTILATION THROUGHOUT
THE BOAT. The forward and a canvas panels must be
removed to allow air ow through the boat so Carbon
Monoxide cannot accumulate.
walls. Make sure that the panels are fully engaged into the slots. Place the center panel in between
the outboard panels locking the sun lounge into posion. Finally, place the cushions onto the sun
lounge.
14. Canvas (oponal)
The oponal canvas consists of a bimini with frame along with vinyl panels which fully encloses the
cockpit.
Bimini
When not in use, the bimini can be stored in an a posion where it does not interfere with the use of
the boat. In this posion, always make sure that the bimini is secured in the canvas boot. To use the
bimini, remove the canvas boot and rotate the two bimini frames forward and secure the bimini
straps to the deck trail. DO NOT OPERATE YOUR BOAT WITHOUT THE BIMINI STRAPS ATTACHED TO
THE DECK.
Bimini with Enclosure
In addion to the bimini, clear vinyl panels can be installed to enclose the cockpit. Each panel aaches
to the bimini with a zipper and snaps or studs are used to aach to the deck.
