Before trimming the engine to trailer mode, make sure that
the back bench backrest is rotated forward. Failure to do so
could cause damage to the engine and bench seat.
11. Center A Bench Seat Backrest
Located on the a bench seat, the center backrest can be rotated forward so that the engine can be
raised to “trailer” posion. To rotate, simply unlatch the backrest and ip it forward.
A bench seat back
Back bench seat back
Latches
12. Helm Seat Conguraons
The helm bench seat has an arculang support bar that allows for mulple seang conguraons.
With the support bar located in the a posion, you can comfortably sit while operang the boat. By
rotang the support bar to the center posion, you can now operate the boat in a standing posion
and use the support bar as a bolster to lean on. Finally, by rotang the support bar to the forward
posion, you can comfortably sit at the helm seat facing a while the boat is at rest.
Helm Seat Posions
Facing forward Facing a Center posion
Do not operate the boat with the center a bench seat
backrest rotated forward. Failure to do this could lead to
injury or death from falling overboard.
