Quicksilver 505OP — System & Component Overview and Operaon
13. Bow Sun Lounge Kit and Extension (oponal)
As an opon, your boat may be equipped with a removable sun lounge. The sun lounge kit consists
of a hinged ller panel, and cushions. To install the lounge, simply place the ller panel between the
console seat and the bow hatch. Make sure that the panels are fully engaged into the deck and
console details. Then snap the cushions into place.
As an addional opon, your boat may be equipped with removable sun lounge extensions. These
extensions are also self locking between the console seat, sun lounge ller and the cockpit walls.
Sun lounge may shi while underway. Verify that the outer
sun lounge panels are fully engaged into the deck support
slots and the center sun lounge panel locks in posion.
Console back rest
Console seat cushion
Bow conversion cushion
Bow cushion
Sun lounge extension port cushion
Sun lounge extension stb cushion
Sun lounge extension port panel
Sun lounge ller panel
Sun lounge extension stb panel
Bow sun lounge kit
Bow sun lounge kit with extensions
14. Ski Pole (oponal)
Your boat may come equipped with an oponal ski pole for water skiing. To use, remove the ski pole
deck plate, located on centerline in front of the motorwell. The ski pylon slides into the deck plate and
connects to the ski tow base, located in the bilge.
The ski tow deck plate has rubber O-ring gaskets to minimize the amount of water that could
potenally enter the bilge. Quicksilver® suggests that prior to installing or removing the ski pylon,
spray water on the ski pole to help slide it through the deck plate.
When the ski pole is not in use, it can be stored inside the a bench seat.
The ski pylon is only used for water skiing or wakeboarding. If you are tubing or engaging in other
recreaonal towing, Quicksilver® recommends that you aach the tow rope to the stern eyes at the
transom of your boat.
