8. Installation
8.1 Installation Dimension Diagram
Installation dimension diagram
Space to the ceiling
Space to the wall
At least 0.5ft.
At least 0.5ft.
At least 0.5ft.
At least 8.2ft.
Space to the wall
Space to the obstruction
roolf eht ot ecapS
Space to the obstruction
Drainage pipe
Space to the wall
Space to the obstruction
Space to the obstruction
Space to the obstruction
At least 10ft.
At least 1.6ft.
At least 6.6ft.
At least 1ft.
At least 1ft.
At least 1.6ft.
