Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Outdoor Unit Model QS09-VP115 QS12-VP115
Outdoor Unit Product Code CB190W0041_K90639 CB190W0061_K90639
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO., LTD
ZHUHAI LANDA
COMPRESSOR CO., LTD
Compressor Model QXA-A091zE190 QXA-A091zE190
Compressor Oil FVC68D/RB68EP FVC68D/RB68EP
Compressor Type Rotary Rotary
Compressor LRA. A / /
Compressor RLA A 16.03 17.53
Compressor Power Input W 980 980
Compressor Overload Protector 1NT11L-6233 1NT11L-6233
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range °F 61~86 61~86
Cooling Operation Ambient Temperature
Range
°F 55~115 55~115
Heating Operation Ambient Temperature
Range
°F 5~75 5~75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter inch Φ3/8 Φ3/8
Condenser Rows-n Gap inch 2-1/16 2-1/16
Condenser Coil Length (LXDXW) inch 29 2/5X1 3/4X20 29 2/5X1 3/4X22
Outdoor Unit Fan Motor Speed rpm 900 900
Outdoor Unit Fan Motor Power Output W 30 30
Outdoor Unit Fan Motor RLA A 0.17 0.17
Outdoor Unit Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 1059 1177
Outdoor Unit Fan Type Axial-ow Axial-ow
Outdoor Unit Fan Diameter inch 15 3/4 15 3/4
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 53/50/46 55/53/49
Sound Power Level (H/M/L) dB (A) 63/60/56 65/63/59
Dimension (WXHXD) inch 33 2/5X21 1/4X12 3/5 33 2/5X23 1/3X12 3/5
Dimension of Carton Box (LXWXH) inch 34 4/7X14 1/6X22 5/6 34 4/7X14 1/6X24 4/5
Dimension of Package (LXWXH) inch 34 2/3X14 2/7X23 3/7 34 2/3X14 2/7X25 2/5
Outdoor Unit Net Weight lb 72.8 75
Outdoor Unit Gross Weight lb 81.6 83.8
Refrigerant R410A R410A
Refrigerant Charge oz 42.3 45.8
Connection
Pipe
Connection Pipe Length ft 25 25
Connection Pipe Gas Additional Charge oz/ft. 0.22 0.22
Outer Diameter Liquid Pipe inch 1/4" 1/4"
Outer Diameter Gas Pipe inch 3/8" 3/8"
Max Distance Height ft 32.8 32.8
Max Distance Length ft 49.2 65.6
