9.8 Technical data controller
General
Supply voltage 24 V AC /16 VA 50/60Hz (+40%/-30%)
24 V DC/0.7 A
Type of protection IP54 (front)
IP21 (back)
• Operating temperature
range
• Storage temperature
range
• -10°C…..+60°C (14 °F .....140 °F)
• -30°C…..+70°C (-22 °F ......158 °F)
Permissible humidity Relative humidity 90%
No condensation
Mounting Cabinet door
Digital outputs
Number of outputs 9 (Q-Control Touch)
Type Relay (voltage free contacts)
Rated voltage AC 250 V AC / 10 A max.
Rated voltage DC 30 V DC / 10 A max.
Digital inputs
Number of inputs 10 (Q-Control Touch)
Supply by controller 24 V DC
Supply protection Short circuit protected to ground
Input protection Not isolated
Analog inputs
Number of pressure inputs 2 (Q-Control Touch)
Number of temperature inputs 5 (Q-Control Touch)
