Quincy Compressor QPNC 10 Instruction And Maintenance Manual

ENGLISH
6 - Edition 10/2014 Cod. 2200780113 01 -
TYPE
Net Weight
lb. (Kg.)
Refrigerant
R134a
lb. (Kg.)
Nominal
Power
HP (W)
MAX.
psi (bar)
V230/115-60Hz
V230-60Hz
V115-60Hz
V230-60Hz
V115-60Hz
V230-60Hz
V115-60Hz
QPNC 10
41,9 (19)
0,397 (0,180)
0,161 (120)
0,164 (122)
0,040 (30)
0,040 (30)
0,201 (150)
0,204 (152)
232 (16)
QPNC 15
44,1 (20)
0,463 (0,210)
0,205 (153)
0,212 (158)
0,040 (30)
0,040 (30)
0,245 (183)
0,252 (188)
232 (16)
QPNC 25
55,1 (25)
0,639 (0,290)
0,312 (233)
0,306 (228)
0,040 (30)
0,040 (30)
0,353 (263)
0,346 (258)
232 (16)
QPNC 35
59,5 (27)
0,970 (0,440)
0,390 (291)
0,386 (288)
0,040 (30)
0,040 (30)
0,430 (321)
0,426 (318)
232 (16)
QPNC 50
59,5 (27)
1,047 (0,475)
0,417 (311)
0,441 (329)
0,040 (30)
0,040 (30)
0,457 (341)
0,481 (359)
232 (16)
Reference conditions:
Limit conditions:
Ambient temperature: + 100 °F (+ 38 °C)
Max. ambient temperature: + 115°F (+ 46 °C)
Inlet air temperature: + 100 °F (+ 38 °C)
Min. ambient temperature: + 34°F (+ 1 °C)
Working pressure: 102 psi (7 bar)
Max. inlet air temperature: + 131°F (+ 55 °C)
Dew point in pressure: + 39°F (+ 4 °C)
Max. working pressure: 232 psi (16 bar)
14.0 MACHINE ILLUSTRATION
14.1 GENERAL LAY-OUT
14.2 COMMAND AND CONTROL PANEL
BEFORE CARRYING OUT THE OPERATION TEST, READ CAREFULLY AND ACQUIRE A GOOD KNOWLEDGE OF THE COMMAND
FUNCTIONS.
Ref. 1) Digital controller
Ref. 8) Stop - Running button
ICON
MODE
FUNCTIONS
ALARM
OFF
No active alarms
ON
Probe failure alarm
High/Low temperature alarm
COMPRESSOR
OFF
Dryer off
FLASH
Maintenance warning
ON
Dryer on
FAN
OFF
Fan off
FLASH
n/a
ON
Fan on
2
Alarms
3
Power ON
4
Fan ON
5
PDP temperature
6
Unit °C or °F
7
Alarms led
Nominal
Power
HP (W)
Nominal
Power
HP (W)
FIG. 8
1
Refrigerant compressor
2
Condenser
3
Motor fan
4
Evaporator
5
Condensate drain
6
Hot gas by-pass valve
7
Refrigerant filter
8
Expansion capillary tube
1
2
4
5
6
7
3
8
FIG. 9
1
5
6
4
3
2
7
8
1
