Section II - Description
Quincy Compressor-QSI
®
11
Indicators
Main Power on Light
Indicates when power from the main disconnect switch
has been turned on and there is live power at the com-
on as long as there is power to the unit, regardless of the
CAUTION!
Always check power supply disconnect. The
Power-on light may be inoperable.
High Discharge Air Temperature Light
Indicates when the unit has sensed an unusually high
Fluid Filter Change Light
Air/Fluid Separator Element Dierential Light
-
Air Intake Filter Service Light
Gauges
Hourmeter
Air Pressure Gauge
This gauge indicates air pressure available for distribution
CAUTION!
Gauge may not register when the unit is unloaded
or o. Make certain all air pressure is relieved
prior to servicing.
Air Outlet Temperature Gauge
-
Percent Capacity Gauge
This gauge is graduated in percent of the total capacity of
-
To Next Page
