Overview of Nordic single tap installation
It is recommended that you install the Quooker in the following order:
A. Drilling hole
B1. Fitting Nordic single tap
C. Connecting water
D. Connecting waste
E. Connecting tank
Note: Bear in mind that the tank, inlet combination, mixing valve and socket must remain
accessible for servicing.
For an overview of the Fusion tap installation, please refer to the next page and for the Flex tap to
the page after that.
