R1 WURKS LCG Digital-3 2S/1S User Manual

13
12. Specification
DIGITAL-3
Motor Type
Sensored / 4Pole Sensored
Motor Limit
“Specification when using the fan”
>3.5T
Operating voltage
3.7-7.4V
Forward / Brake / Reverse
yes
Full aluminum case / heat sink
yes
Typ. Voltage Drop @20A per phase
0.0048V
Rated Current per phase
2549A
Plugged 30x30x10mm Fan
yes
BEC Output
6V/7.4V Bulit-in DC Booster, Continuous Current of 3A
Multi-Protection-System
yes
“Boost 0” Mode
yes
Multi-frequency system
yes
Power Wires
12Awg
USB Software Updateability
yes
Case Size(without fan)
32.9 x 34.6 x 21mm
Weight(without cable)
50g

R1 WURKS LCG Digital-3 2S/1S Specifications

General

Brand	R1 WURKS
Model	LCG Digital-3 2S/1S
Category	Controller
Language	English
