MOUNTING THE SEAT
ON A TOILET
To be able to mount the Flamingo seat on
a standard toilet, an extra fitting must be
ordered and the following instructions must be
followed:
1) Making the seat ready:
* Dismount the seat (see page 15)
* Remove the mounting for commode pan, if
any.
* Place the new seatframe underneath the
seat.
* Place the support-fitting (A) in front of the
seatframe, as the seatframe is pushed
into place. Fasten with the screws on both
sides.
* Mount the mounting-bars (B) on the seatframe
with the enclosed screws.
* The two support fittings (C) must be mounted
underneath the seat, in the holes in the
back.
2) Making the toilet ready:
* Remove the toiletseat (D)
* Place the mounting (E) and fasten together
with the toiletseat as shown.
Finally mount the Flamingo seat on the toilet by
leading the mounting-bars into the mounting.
Fasten with the screws on both sides (F).
GB
1
A
2
B
C
D
E
F
