Microwave Motion Sensor
Page 1.
PERFORMANCE
Operating voltage
12 ± 2V DC
Operating current 30mA
Output DIM 0-10V
Stand-by power <0.5W
Brightness 70%/80%/90%/100%
Detection area 20%/50%/75%/100%
Hold time 10s/1min/10min/30min
Daylight threshold 10Lux/30Lux/50Lux/100Lux/Disable
Stand-by period 1min/30min/60min/+∞
Stand-by dimming level 10%/20%/30%/50%
Microwave frequency 5.8GHz ± 75MHz
Microwave power <0.5mW
Detection angle 30-150°
Control line Black/White:12V+ ; Purple: DIM+ ; Pink: 12V-/DIM-
Mounting height Max 15M (ceiling mounted)
Detection range Max Ø15m (ceiling mounted) Max 20m(wall mounted)
Operating temperature -25°C~+60°C
IP rating IP65
OPTIONAL REMOTE
Not Included (Order REMOTE-OD)
MVS-OD SENSOR
RoHS
IP RATING
10-15M FIXTURE
ALTITUDE
