RAB A17 - Wiring Diagram

Microwave Motion Sensor
Page 2.
.
DIMENSIONS
2 1/4"
4"
Weight: 0.14lb
Ceiling Mounted
Mounting
Mounting
Height
Covered
Well Covered
Wall Mounted
Lux o
Lux on
Natural light
light on automatically
light o automatically
10 8 6 4 2 2 4 6 8 10
2
4
6
10
12
14
16
8
18
2 4 6 8 10 12 14 16 18
4
3
2
1
1
2
3
4
DETECTION COVERAGE
L
N
Pink
Purple
Black/White: 12V+
LED Driver
LED Driver
Black/White
Purple: DIM+
Pink: 12V-/DIM-
WIRING DIAGRAM
Height
MVS SENSOR FACTORY SETTINGS
BRIGHTNESS 100%
HOLD TIME 1 Minute
DAYLIGHT Disabled
SENSITIVITY
50%
STAND-BY DIMMING LEVEL 20%
STAND-BY TIME 1 Minute
