Microwave Motion Sensor
LUX ON-OFF
Ceiling Mounted
Mounting
Mounting
Height
Covered
Well Covered
Wall Mounted
Lux o
Lux on
Natural light
light on automatically
light o automatically
10 8 6 4 2 2 4 6 8 10
2
4
6
10
12
14
16
8
18
2 4 6 8 10 12 14 16 18
4
3
2
1
1
2
3
4
Sensor automatically turns o light when ambient brightness exceeds preset lux level. Following preconditions apply to use the Lux On-
O function:
• Stand-by period : +∞
• Stand-by dimming level : 10%, 20%, 30% or 50%
• Daylight threshold : 10Lux, 30Lux, 50Lux or 100Lux
When ambient brightness
is lower than preset lux
level, light automatically
turns on
When ambient brightness
is higher than preset lux
level, light automatically
turns o
Light dims to stand-by
level when there is no
motion detection after
hold time
When motion detected
while ambient brightness is
insucient, light DIMs 100%
