RAB Lightcloud Blue XDIM/LCB - Page 14

Installing your Lightcloud Blue Device
(cont’d)
Wiring Scheme 2 (hot wire only)
Hot/Line
Load
(Light(s))
Location 1
Dimmer
Copper
screw
Brass
screw
Black
screw
Green
screw
Silver
screw
Ground
(Green or Bare Copper)
N
P
L
LD
Line
Brass screw
(load)
Dimmer
(Neutral)
N
P LD
L
Hot
Neutral
Ground
Load
screw
screw
Copper
Silver screw
Black screw
Green
