A.3 Jumper Configurations
Figure A-2 shows the header and jumper locations used to configure the various BL1810
options.
Figure A-2. Location of BL1810 Configurable Positions
R55
R56
D21
C27
D24
JP2
R16
R17
R18
JP1
Z-World, Inc.
JACKRABBIT
JP3
Top Side
Bottom Side
CAUTION
Battery
