TCP-IP Configuration

There are two methods for setting up the IP address: Dynamic IP Address assignment and

Manual IP Address assignment. If you are uncertain which method to use, contact your network

administrator for assistance before continuing the installation process.

Dynamic IP Address Assignment

Connect the PDU to a network. While the PDU is powered on, connect a standard Ethernet cable

to the RJ45 Ethernet port, the activity LED will light up to indicate Ethernet connectivity.

1. Press MENU until the Main menu appears, select Ethernet or Network using UP and DOWN

and press OK.

2. Within the Ethernet or Network menu, select DHCP (off) and press OK until DHCP (on)

appears.

3. Press MENU to return to the Main menu and use UP and DOWN to select Current IP-

Address. The current IP-address is shown in yellow at the bottom of the OLED.

4. On a computer in the same network, use a browser to open the assigned IP-address, for

example http://192.168.14.250

5. When browsing to the Web Portal, a popup appears requesting a username and password.

The default values are:

Password: 1234
