Using the Web Portal
Opening the Web Portal
Use a browser to open the PDU IP address. You will be asked for login credentials, the default
values are:
Login: admin
Password: 1234
Status tab
• The Status Screen shows the ON/OFF status of the 8 ports on the PDU
o Grey background: port is powered OFF
o Green background: port is powered ON
• The button underneath each port toggles the port status instantly (even when a delay
has been set on the Protection tab). The load is activated at the zero crossing of the
voltage to avoid interference on the voltage. Toggling a port state always triggers an
SNMP Trap, regardless of other settings.
• For each port, the real time True RMS is displayed (in Ampère)
• The default port names (port1, port2,...) can be changed at the Settings tab.
Power tab
This tab shows all the power measurements in real time.
• Port: Port name and status
o Grey background: Port is powered OFF
o Green background: Port is powered ON
• Current: The real time current is displayed (in Ampère)
• Maximum: The maximum current measured (in Ampère). Hover your mouse over this
value to see a timestamp that indicates when the maximum value was measured. This
value can be reset at the Protection tab
• Real Power: The real power usage (in Watts)
• Apparent Power: The apparent power (in Volt Ampère)
• Power Factor: The power factor (in %)
• Resettable kWh: The total amount of kilowatt hours since the last reset
• Resettable kVAh: Total apparent power (in kilo Volt Ampère hours) since the last reset
• Reset: Resets the Resettable kWh and the Resettable kVAh (note: this reset will not clear
the maximum column, this can be done at the Protection tab)
• kWh: The total kilowatt hours since the PDU has been in use. This value can NOT be
reset.
The default port names (port1, port2,...) can be changed at the Settings tab.
