Serial tab
The settings for the PDU's 4 serial connectors can be changed on this tab.
• Port: The number of the serial connector as seen on the front of the PDU
• Baudrate: Possible baudrates for serial communication. The baudrate of the serial
connector and a connected device must be the same
• TelnetPort: Sets the telnet port. The port must end in the same number as the
corresponding serial connector (serial connector 3 cannot have a port ending with 4 (ie:
30004), it must end with a 3 (ie: 14203)
• Reset Telnet: Disconnects an active telnet session. This button does not alter any other
settings.
After editing the settings on the Serial tab, press the Save Data button. A pop-up will appear after
the changes have been successfully saved.
Schedule tab
Here you can specify a schedule which defines for each port if and when it should be turned off
and/or on and if this should be repeated on a daily basis.
• Port: Port name and status
o Grey background: Port is powered OFF
o Green background: Port is powered ON
• Time Off: Time in hours:minutes when the port is to be turned off (with Off Enable
checked)
• Off Enable: When checked the port will be turned off at the time specified in Time Off
• Time On: Time in hours:minutes when the port is to be turned on (with On Enable
checked)
• On Enable: When checked the port will be turned on at the time specified in Time on
• Repeat Daily: When checked the specified schedule for that port will be repeated daily
The current time is displayed below the table.
After editing the settings on the Schedule tab, press the Save Data button. A pop-up will appear
after the changes have been successfully saved.
Logging tab
The PDU’s short- medium- long- and event logging are displayed on this tab. For each type the
number of items needed can be specified. Changing the logging intervals can be done at the
Settings tab.
