Waveform Output
1
Sensitivity 20mV/kV
200mV/R/s
2
0.5mV/mA
3
Full scale 4V
Output impedance 100 Ω
Sample Rate 77 μs
0.5 db frequency 1.0 kHz
3 db frequency 2.3 kHz
1
Waveform only available in kV modes
2
Requires 40X11-W and DDX10 -W or 40X10-M and DDX10-M
3
Requires mA sensor 90M9 or 90M10
Part number reference
Part numbers
Description Part Number
Control Unit 9096
Sensor Cable (4m) 90C6-4
Diagnostic Accu-kV sensor (with auto compensation) 40X12-W
Mammographic Accu-kV sensor 40X9-Mo
Dose diode digitizer DD60
Diagnostic Dose diode sensor DDX6-W
Mammographic Dose diode sensor DDX6-M
Description Part Number
Ion Chamber digitizer 9660
6cc Ion Cham ber 10x6-6
Mammographic Ion Chamber 10x6-6M
60cc Ion chamber 10x6-60
CTDI Ion chamber 10x6-3CT
180 cc Ion chamber 10X6-180
1800 cc Ion Chamber 10X6-1800
Extension cable (2m) 90E6-2
Invasive mA Sensor 90M9
Noninvasive mA sensor 90M10
36
