Radial Engineering JDX User Manual

True to the Music
Radial Engineering
JDX User Guide
9
JDX Specifi cations
Circuit type: Class-A 100% discreet
Speaker emulation Reactive load sensing with
proprietary band pass fi ltering
Total harmonic distortion 0.005 % @ 1KHz
Amp input 1/4", 300 watts max
Speaker thru-put 1/4", paralleled to amp input
Balanced outputs XLR 600, -60dB mic-level
XLR pin confi guration AES standard: pin 1 ground
pin 2 hot (+)
pin 3 cold (-)
Power supply (included) 15VDC, 400mA current draw
Size (W x D x H) 3.25”x 5”x1.75” (83x126x45mm)
Weight 1.5 lbs. (.7 kg)
Warranty 3 Years, transferable
