Radial Engineering SHOTGUN User Manual

Radial Engineering Ltd. Shotgun™ User Guide
7
(A)
(A)
(A)
(B)
(B)
(B)
Using the Shotgun in stereo
In setups where you may have a stereo chorus or multi-tap delay on your pedalboard, sending the output from the stereo pedal
to your amps will often cause hum and buzz due to a ground loop. This is because most pedals are not equipped with isolation
transformers or ground lift switching to prevent noise.
Simply connect the left and right outputs from your chorus to the Shotgun’s 1 and 2 inputs. Once connected to input-2, the
Shotgun will automatically shift from mono-mode to stereo-mode. When in stereo-mode, input-1 is routed to outputs 1 and 2,
while input-2 is routed to outputs 3 and 4. Connect output-1 to your left amp and output-3 to your right amp. You can then add
two more amps on each side for larger stages.

Radial Engineering SHOTGUN Specifications

General

Brand	Radial Engineering
Model	SHOTGUN
Category	Music Equipment
Language	English
