Radial Engineering Ltd. Trim-Two™ Stereo Direct Box User Guide
9
Audio circuit type: .................................................................................................................... Passive transformer isolated
Frequency response: ..................................................................................................................... 20Hz to 20kHz (-1/+3db)
Total Harmonic Distortion: (THD+N) ...................................................................................... 0.009% (1kHz with 100k load)
Dynamic range: .................................................................. >126dB (difference between noise oor and maximum output)
Input impedance: .............................Approx 10k with 100k load (depends on load impedance; about 6k with mono mode)
Maximum input: ..................................................................................................................................................... > +20dBu
Gain: ................................................................................................................... -1dB (10k load; level control at maximum)
Clip Level - Output: ................................................................................................................................................ > +11dBu
Output impedance: ..................................................................2800Ω (level control at maximum; higher at lower settings)
Noise oor: ........................................................................................................................................................... < -115dBu
Intermodulation distortion: ............................................................................................................. extension (-10dBu input)
Phase Deviation: ........................................................................................................ <10° (20Hz to 20kHz with 100k load)
THD+N: ...............................................................................................................................................0.006% (-5dBu input)
Input pad:...............................................................................................................................................Variable trim control
XLR conguration: ................................................................................................ Pin-1 ground; pin-2 hot (+); pin-3 cold (-)
Other connectors: ............................................................................................................ 1/4” TRS, RCA and Mini Phone In
Power: ............................................................................................................................................................None, passive
Construction: ............................................................................................................................................... Steel Enclosure
Size: (LxWxD) ............................................................................................... 5” x 3.3” x 1.8” (127mm x 84.1mm x 45.5mm)
Weight: .................................................................................................................................................1.55 lbs (703 grams)
Shipping size: ...................................................................................................... 6.5” x 4” x 3” (165mm x 102mm x 76mm)
Shipping weight: ................................................................................................................................1.92 lbs (870.9 grams)
Warranty: .................................................................................................................................... Radial 3-year, transferable
