INSTALLATION & OPERATION INSTRUCTION
CLEARANCE
Combustible Construction
BACK
SIDES
FLOOR
8”
12”
Non-Combustible
0
0
6”
Non-Combustible Construction
The appliance area must be kept free and clear of all combustible. This unit is design-certified for
the following installation only:
The clearances from combustible and noncombustible construction for ranges and range mounted
salamander broiler or cheesemelter are as follows:
CAUTION
DO NOT PUSH against the end of the valve cover/landing ledge in an attempt to adjust the ranges
position. Although this part is deburred during manufacturing; an accident could occur if the range
should move suddenly while being pushed onto position by hand.
HIGH SHELF ASSEMBLY
(1) Mount the high shelf riser to the range with #10 sheet metal screws(pointed tips) in the back.
(2) Mount the high shelf to the riser with #10 sheet metal screws provided (See attachment at the
end of this manual for a diagram that describes the installation of the backguard/flue riser).
NOTE: If a Salamander broiler / Cheesemelter is to be mounted on range, read installation instruc-
tions for Salamander broiler / Cheesemelter before installing high shelf. Special care must be taken
to ensure that the gas supply piping and/or gas pressure regulator is not exposed to exhaust gases
or elevated temperatures.
If legs or casters are not used, the unit must extend 2" beyond the front edge of a non-combustible
curb or platform.
