6
Note:
This input is designed to receive the Channel 3/4 output from
your VCR.
From Cable TV
To connect direct cable TV signals to the video selector without a
cable box, connect the 75-ohm coaxial cable to the video selector's
CABLE INPUT
jack.
From an Antenna
To connect an antenna to the video selector, connect the antenna's
75-ohm coaxial cable to the video selector's
ANT INPUT
jack.
Notes:
• If your antenna wire is 300-ohm twin-lead, you need a
300-to-75-ohm matching transformer.
• If you have separate VHF and UHF antennas, use a signal
combiner.
You can find the necessary connection accessories at your local
RadioShack store.
From an Auxiliary Device
To connect an auxiliary device (such as a computer or video disc
player) to your video selector, connect the device's output to the
video selector's
AUX-1
or
AUX-2
jacks.
Note:
These outputs are designed to receive the Channel 2/3/4
outputs from your auxiliary devices. If your auxiliary devices use
other output channels, they might not work properly with this selec-
tor.
