Radio Thermostat CT50 Install Guide

PG 6
PG 7
Mount the CT50 to Wall
1. Hold the CT50 against the wall, with the wires coming over the top;
above terminal block. The CT50 will cover the hole in the wall.
2. Position CT50 for best appearance.
3. Attach the CT50 to the wall with the screws provided.
4. If you are mounting the CT50 to sheet rock or if you are using the
old mounting holes, use the plastic anchors provided.
5. Mark rst and drill a 3/16-in.(4.8mm) hole for the insert at each
screw location, then mount the unit.
Screw to wall
Place wires like this
C
B
O
W
W
2
Y
Y2
R
H
R
C
G
A
from
HEAT/COOL
system
C
B
O
W
W
2
Y
Y2
R
H
R
C
G
A
C
W
Y
RH
G
Wall
Wires
Wall
anchor
CT50
