Keypad actions and shortcuts
Switch the locator or transmitter on by pressing the key. Once powered up, the keys
function as follows:
Locator keys
KEY
● SHORT PRESS
●■■■● LONG PRESS
Enter the menu. Switch power off.
Scroll through locate frequencies
from low to high.
–
When using active frequencies:
Toggles Peak, Peak+, Null, and Guidance
antenna modes.
PL & PLG models in Power Mode:
Scrolls through Power Filters
™
for improved
discrimination of parallel or strong power
signals.
In Peak+ antenna mode:
Switch between Guidance and Null arrows.
and
Increase and decrease gain.
RD7100 automatically sets gain to
mid-point when pressed.
Rapidly increase and decrease gain steps
in 1dB increments.
KEY
● SHORT PRESS
●■■■● LONG PRESS
Enter the menu. Switch Power off.
Scroll through locate frequencies
from low to high.
–
Take voltage and impedance measurements
using the currently selected frequency.
Take voltage and impedance
measurements at a standardized frequency.
and
Adjusts the output signal.
Select standby
/ maximum standard
power
.
Transmitter keys
Tip: to scroll through frequencies from high to low, hold while pressing the button
(applies to both locators and transmitters).
