13
ENGLISH
• MODEL: Match the transmitter setting to the model of your locator.
• MAX V: Set the output voltage to maximum (90V).
Examples of using the menu, selecting options and
making changes:
Locator mains power frequency
To select the correct frequency (50 or 60Hz) for your country or region’s power supply:
1. Press the
key to enter the menu.
2. Scroll to the POWER menu using the
or
keys.
3. Press the
key to enter the POWER menu.
4. Use the
or
keys to select the correct mains frequency.
5. Press the
key twice to accept your selection and return to the main operation
screen.
Batteries
It is important to set the system to match the currently installed battery type to ensure
optimal performance and correct battery level indication.
To set your battery type:
1. Press the
key to enter the menu.
2. Scroll to the BATT menu using the
or
arrows.
3. Press the
key (locator) or the key (transmitter) to enter the BATT menu.
4. Scroll up or down to select the correct battery type (Alkaline, Nickel-metal Hydride
or Lithium-Ion). Lithium-Ion is automatically selected when a Li-Ion pack is connected
to a locator.
5. Press the
key twice to accept your selection and return to the main operation screen.
Transmitter Eco Mode
When using alkaline batteries, Eco mode can be selected to maximize run time. When
Eco mode is selected the transmitter automatically reduces its maximum power output as
battery levels run low. Eco mode is switched off by default. To Enable Eco Mode:
1. Press the
key to enter the menu.
2. Scroll to the BATT menu using the
or
arrows.
3. Press the
key to enter the BATT menu.
4. Select the ALK Battery type using the
or
arrows.
5. Press the
key to enter the ECO sub menu
6. Select ECO using the
or
arrows.
7. Press the
key three times to accept your selection and return to the main
operation screen.
