D2112/D2112E Installation Manual
Page 3
74-07111-000-D 1/96
© 1995 Radionics
Notice ............................................................... 2
FCC Notices ..................................................... 2
Introduction ........................................................... 4
D2112/D2112E Control/Communicator ............ 4
Ordered Separately .......................................... 4
Enclosure Options ............................................ 4
Listings and Approvals ..................................... 4
Getting Started ...................................................... 4
Before You Begin ............................................. 4
Mount the Enclosure......................................... 5
Run the Premises Wiring .................................. 5
Connect Earth Ground
Terminal 3......................................................... 6
Charge the Battery as You Work ......................... 6
Lock the Standby Switch .................................. 6
Transformer
Terminals 1 and 2 ............................................. 6
Battery
Terminals 4 and 5 ............................................. 6
Install Detection Devices, Keypads, and Bells... 7
No Connections to the Panel Yet ..................... 7
Number of Sensors........................................... 7
Continue Connections
to the Panel ............................................................ 7
Power Down First ............................................. 7
Alarm Output
Terminals 6 and 7 ............................................. 7
Keypads
Terminals 8, 9, and 10 ...................................... 8
Auxiliary Power
Terminal 9......................................................... 8
Testing and Replacing D2112E Fuses ............. 9
External Relays
Terminals 11 and 12 ......................................... 9
Connect the Points ............................................. 10
Point 1 on the D2112 Only
Terminals 13 and 14 ....................................... 10
Points 2 to 6 (1 to 6 on D2112E)
Terminals 15 to 22 (14 to 22 on D2112E) ...... 10
Points 7 and 8 on the D2112 Only
Terminals 23 to 25 .......................................... 10
Program the Panel.......................................... 12
Make the Telephone Connections ..................... 12
Power Up ........................................................ 12
Fill out the Point Chart .................................... 12
Unlock the Standby Switch ............................. 12
Test the System.............................................. 13
Detailed Panel Description ................................. 13
Primary (AC) Power Circuit ............................ 13
Secondary (DC) Power ................................... 13
Power Outputs ................................................ 14
Telephone....................................................... 14
Points.............................................................. 15
Keyswitch ....................................................... 15
Installation Guide for UL Applications.............. 17
Introduction ..................................................... 17
Optional Compatible Equipment ..................... 17
Current Rating Chart for Standby Battery Calcu-
lations................................................................... 18
Standby Battery Requirements....................... 18
System Chart ....................................................... 19
System Wiring Diagram, Issue A ....................... 20
Specifications...................................................... 21
D2112/D2112E Terminal Quick Reference ........ 22
Table of Contents
