Radionics D8128D User Manual

D8128D
Installation
D8128D OctoPOPIT Module Installation Instructions
© 2001 Radionics Page 15 41343D
3.4.2 D8128D OctoPOPIT Switch Settings for D7412 and D7212
ZONEX 1 D8128D Address Switches
Points 9-75 1 2 3 4 5
9-16 ON ON ON ON *
17-24 ON ON ON OFF *
25-32 ON ON OFF ON *
33-40 ON ON OFF OFF *
41-48 ON OFF ON ON *
49-56 ON OFF ON OFF *
57-64 ON OFF OFF ON *
65-72 ON OFF OFF OFF *
Refer to the table at right to
set the OctoPOPIT switches
for use with the D7412 and
D7212
Control/Communicators.
* Line Termination Switch
(see section
3.1.1.2 Line Termination
Switch Settings).
Note: For the OctoPOPITs
assigned to points 73-75, be
sure to set Point Input
Switches 4-8 to the OFF
position.
73-80 OFF ON ON ON *
Table 6: OctoPOPIT Settings - D7412 and D7212
3.4.3 D8128D OctoPOPIT Switch Settings for D9112B1
ZONEX 1 D8128D Address Switches ZONEX 2
Points 9-72 1 2 3 4 5 Points 73-135
9-16 ON ON ON ON * 73-80
17-24 ON ON ON OFF * 81-88
25-32 ON ON OFF ON * 89-96
33-40 ON ON OFF OFF * 97-104
41-48 ON OFF ON ON * 105-112
49-56 ON OFF ON OFF * 113-120
57-64 ON OFF OFF ON * 121-128
Refer to the table at right to
set the OctoPOPIT switches
for use with the D9112B1
Control/Communicator.
* Line Termination Switch
(see section
3.1.1.2 Line Termination
Switch Settings).
Note: For the OctoPOPITs
assigned to points 65-72 or
129 - 135, be sure to set
Point Input Switch 8 to the
OFF position.
65-72 ON OFF OFF OFF * 129-135
Table 7: OctoPOPIT Settings - D9112B1
3.4.4 D8128D OctoPOPIT Switch Settings for D7212B1
ZONEX 1 D8128D Address Switches
Points 9-48 1 2 3 4 5
9-16 ON ON ON ON *
17-24 ON ON ON OFF *
25-32 ON ON OFF ON *
33-40 ON ON OFF OFF *
Refer to the table at right to
set the OctoPOPIT switches
for use with the D7212B1
Control/Communicator.
* Line Termination Switch
(see section
3.1.1.2 Line Termination
Switch Settings).
41-48 ON OFF ON ON *
Table 8: OctoPOPIT Settings - D7212B1
