D8128D OctoPOPIT Module Installation Instructions
© 2001 Radionics Page 5 41343D
1.0 Introduction
The D8128D OctoPOPIT Module combines the functions of the D8125 POPEX module and the D8127/D9127
POPIT modules to provide eight off-board points in a single module. You can wire both D8128D OctoPOPIT and
D8125 POPEX modules in parallel to the ZONEX Bus terminals on the same panel.
For a list of compatible panels and accessories, please see section 2.0 D8128D Overview.
1.1 Manual Organization
This manual is divided into three sections and an index. A summary of each section and appendix is detailed in
the table below.
Section Description
1 Introduction
2 Overview
3 Installation
Index The index for this installation guide
Table 1: D8128D Installation Instructions Organization
1.2 Documentation Conventions
These conventions are intended to call out important features, items, notes, cautions, and warnings that the
reader should be aware of in reading this document.
1.2.1 Type Styles Used in this Manual
To help identify important items in the text, the following type styles are used:
Bold text usually indicates selections that you may use while programming your panel. It may
also indicate an important fact that should be noted.
Bold Italicized used to denote notes, cautions and/or warnings
Italicized text used to reference the user to another part of this manual or another manual entirely.
It is also used to symbolize names for records that the user will create.
Courier Text indicates what may appear on the D5200 Programmer display, command
center/keypad or internal printer.
[CAPITALIZED TEXT] used to indicate to the user that a specific key should be pressed.
Example: …press the [ESC] key…
1.2.2 Tips, Important Notes, Cautions and Warnings
Throughout this document, helpful tips, important notes, cautions and warnings will be presented for the reader
to keep in mind. These appear different from the rest of the text as follows;
Important Notes - should be heeded for successful operation and programming. Also tips and
shortcuts may be included here.
Caution - These caution the operator that physical damage to the program and/or equipment may
occur.
Warning - These warn of the possibility of physical damage to the operator, program and/or
equipment.
1.3 Listings
The D8128D OctoPOPIT Module is UL listed for Local or Police Connected Burglary Alarm, Central Station
Burglary Alarm, and Household Burglary Alarm applications. The D8128D is also suitable for fire supervisory
