21
5.2. USING THE SPRAY NOZZLES
WARNING!
The trigger safety lock MUST be engaged when replacing nozzles
while the engine is running.
High pressure in nozzle area. Risk of injury caused by improperly
locked nozzle.
1. To connect or disconnect a nozzle pull back on the quick connect collar.
Insert or remove the nozzle then release the collar. Tug on the nozzle to
ensure it is secured. The nozzles are color coded and stored on the panel.
Nozzle Selection Guide
0° 15° 25° 40° 65°
Paint Stripping
Concrete
Deck
Gutters
Siding
Vehicles
Windows
Furniture
Detergent
