04
2. Installation Procedure
2.2 Front Wheel Installation
2.1 Handlebar Installation
Remove the pre-tightened set screws of the handlebar end cover using 4mm socket head wrench
Place the handlebar, adjust it to a suitable angle, close the end cover of the handlebar and pre-tighten 4 screws
using 4mm socket head wrench
Tighten set screws of the handlebar end cover in the order of 1, 2, 3 and 4
Align the front disc at the space of the gateway lining, align the front axle at the front fork axle hole and insert it
into the hole
Install gaskets and cap nuts on both sides
Tighten cap nuts on both sides using 15mm open spanner
1
4
3
2
