2.3 Pedal Installation
Differentiate the identifiers of left and right pedals, L means left pedal and R means right pedal
When installing pedals, keep the pedal bolt end face vertical to the mounting hole of the crank and tighten and
fix it using 15mm open spanner
(When installing the left pedal, rotate it anticlockwise; when installing the right pedal, rotate it clockwise)
During installation
Align the left to left and
the right to right
L R
