Rage Eclipse 1M - Final Rigging Adjustments; Bind Transmitter and Receiver

23. Move the bowsie as
shown to tighten or
loosen the main sail.
24. Move the bowsie as
shown to adjust the
bend of the mast. It
should be bent a little
like a bow (as shown by
the dotted line in the
picture). Do not tilt the
mast forward or
backward.
25. Loosen the screw
and move the arm to
adjust the height of th
emain boom. This is
only required when the
cord tied to SR1 is not
at a perfect length.
9/14
