Manual IB-NAS5520
6

HARDWARE
2.
IB-NAS5520
Thisdual‐bayhybridenclosureisafullyfunctionalnetworkdrive(NAS)thatallowsuserstologinover
theinternetplusaUSB3.0directattachedstoragedevice(DAS)forsuper‐speedfiletransfers.The
hardwareRAIDsupportsJBOD,RAID0andRAID1,offeringlargestoragecapacity,performanceand
dataprotection.OurfreeiPhone,iPadandAndroidAppsallowforeasyaccessonmobiledevices.
Comeswithbuilt‐inUPnP‐AVmedia server.

2.1 TECHNICAL DETAILS

CPU 300MHz
Memory 32MBDDR1SDRAM
2MBSPIflash
Internalhard
drive
Two3.5”SATA‐I,SATAIIorSATA‐IIIharddrives(1.5Gbit/sor3Gbit/s
compliant)
Capacity80GB–3TB(supportslargevolumesinexcessof2TB)
exFAT(maximumsizeforsinglefilesonNAS/DASis127GB)
FrontI/O 1xPowerbuttonwithback‐lightindicatingpowerstatus
1xLEDindicatingthesystemstatus(OS)
2xLEDsindicatingtheHDDstatusanddataaccess(HDD1andHDD2)
2xLEDsindicatingthecurrentstoragecapacity(50%and100%)
RearI/O 1xPowerreceptacle
1xRJ45connector(10/100/1000)withtwoLEDsforlinkandactivity
1xUSB3.0deviceport
1xResetbutton
1xFirmwareupdatebutton
1xFirmwareupdateLED
1xRotaryswitchforRAIDmodeselection
1xConfirmationbuttonforRAIDmode
