RaidSonic IB-NAS5520 - 2.2 Front View; 2.3 Rear View

Manual IB-NAS5520
2.2 FRONT VIEW

Powerbutton
Blue=PowerisON
OS Green=Systemisrunningandready
Flashinggreen=Systemisstartinguporshuttingdown
Flashingred=SystemcannotobtainIPaddressorsystemiscurrently
startinguporshuttingdown

Green=OK
Flashinggreen=Dataaccess

Usedstoragespaceinpercentage(50%and100%)

2.3 REAR VIEW
7


USB3.0port
Ethernetport
Green=Networklink
Orange=Networkaccess
FW WhentheLEDislit,pressthebuttontoupdatethefirmware. 
