Rainbow Funhouse - Page 24

76
75
78
H1 H108
H1
H108
H1
H108
76
49
75
78
*NOTE: Pre-drill all holes for Lag Bolts with the appropriate drill bit.
1. Attach Angled Braces (78) to Corner Uprights (75) (76) using 5/16" Hardware (H108) and 1/4"
Hardware (H1) . The tops of the Angled Braces (78) should be touching the bottom of the Deck
Boards.
2. Attach Angled Braces (78) to Main Beams (49) using 5/16" Hardware (H108) and 1/4" Hardware
(H1) .
23
Step 6
Angled Brace Installation
