1. Lay 2 Hole Rockwall Boards
(14) (16)
, 4 Hole Rockwall Boards
(13)
, and Rockwall Legs
(34)
on a
flat, hard surface. Use a hammer to pound in 1/4" Hardware
(H32)
and 3/8" Hardware
(H34)
(as
shown in Inset A). Rockwall Legs
(34)
must be orientated as shown in Inset A.
2. On a flat surface, lay Rockwall Legs
(34)
on edge with holes up. Ends should be flush, and 3/8"
Hardware
(H34)
should be on the outside of each Rockwall Leg
(34)
(as shown). Rockwall Legs
should be positioned so they measure
33 7/8"
apart from outside face to outside face.
*NOTE: The top two Rockwall Boards (14) (13) must be installed after the Rockwall is
attached to the set.
*NOTE: 1/4" Hardware (H32) must be on the bottom side when Rockwall Boards are attached.
3. Attach 2 Hole Rockwall Board
(14)
to Rockwall Legs
(34)
,
11"
down from the top of the Rockwall
Legs
(34)
,
using #8 Hardware
(H152)
in the top two holes only at this time.
4. Position the remaining Rockwall Boards
(13) (14) (15) (16)
along the Rockwall Legs in the order
shown. Rockwall Boards should be tight against each other and should not have gaps between
boards.
5. Check to make sure Rockwall Legs are still
33 7/8"
apart and attach Rockwall Board with Rope Hole
(15)
to Rockwall Legs using #8 Hardware
(H152)
in the bottom two holes only at this time.
6. Measure diagonally across the Rockwall assembly and make adjustments as needed to ensure that
the Rockwall is square.
7. Finish attaching Rockwall Board with Rope Hole
(15)
and top 2 Hole Rockwall Board
(14)
. Continue
attaching Rockwall Boards
(14) (13) (16)
in the order shown using #8 Hardware
(H152)
.
8. Center and attach Rockwall Runner
(36)
to the back side of Rockwall Boards
(13) (14) (15) (16)
using #8 Hardware
(H152)
. Runner
(36)
should be
1/2"
up from the bottom edge of the Rockwall
Board with Rope Hole
(15)
.
9. Attach Rocks
(N21)
to Rockwall Boards
(13) (14) (16)
using 1/4" Hardware
(H7) (H170) (H32)
(as
shown in Inset B).
*NOTE: Rocks (N21) must go on the side of the Rockwall Board opposite the 1/4" Hardware
(H32).
10. Attach 90
Ladder Brackets
(N9)
to Rockwall Legs
(34)
using 3/8" Hardware
(H34) (H11) (H124)
(as
shown in Detail A).
*NOTE: Do not fully tighten Ladder Bracket hardware at this time.
30
Step 13
Rockwall Assembly
