Raisecom
ISCOM2600G (A) Series Product Description
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
Supply 220 VAC power supply.
Support a lightning protection level of 6 kV in both common mode and differential mode.
Interfaces
There is an AC power input interface for inputting AC power on the panel of the ISCO2600
series switch, as shown in Figure 3-35.
Figure 3-35 AC power interface
Parameters
Table 3-11 lists parameters of the AC power interface.
Table 3-11 Parameters of AC power interface
3.3.3 RPS power interface
Introduction
The ISCOM2624G-4GE-RPS-AC and ISCOM2648G-4GE-RPS-AC provide 12 V input RPS
power interfaces. You can purchase RPS power supplies additionally for backup.
Interface
The RPS power interface adopts 2 pins on the 3-pin Phoenix connector (with pin spaces of
5.08 mm), as shown in Figure 3-36and Figure 3-37.
Figure 3-36 ISCOM2624G-4GE-RPS-AC power interface
