30 Raith User Guide
Chemicals should not be used on the motor CAN, only
soapy water and a toothbrush is recommended to be
used to clean the motor CAN and its magnets.
4. Apply new grease, ensuring the bearings are sufficiently
coated, rotating the bearings as your apply.
5. Re-assemble the drive system, screws, wheel and axle
nut. Use the Raith drive service tool or non-ferrous tool
to press the motor back onto the drive collar bearing
ensuring the screw holes line up, rotate to align them.
Make sure to use blue loctite on the M3 drive collar
screws when they are re-installed and torque to spec.
Re-assemble in the same order it was dis-assembled.
TORQUE SPECS
M2 screws - 0.4Nm (finger tight)
M3 screws - 2.2Nm
M4 screws - 4.8Nm
M8 axle nut - 29Nm
M10 axle into hanger - 57Nm
